We are proud to introduce these proven reliable printers to Australia. Backed with local support, training and warranty.
The Inspire D290 is the largest in the Insprire range of professional 3D printers, boasting a 320 x 290 x 255 mm (23.7 litre) build volume.
The Inspire Professional 3D printers are affordable large format 3D Printers that utilise Fused Filament Fabrication (FFF) technology to produce precise durable ABS plastic parts. Ideal for real world functional testing, design verification, low volume production cycles, rapid tooling and more. Parts can be printed in a selection of 6 colours.
The Insprire range of rapid prototyping 3D printers are backed with over 10 years of R&D. Manufactured by TierTime Technology Co. Ltd. Founded in 2003, they are the largest producer of 3D printers in the Chinese market. Now available for the first time in Australia.
These printers outclass the competition with higher resolution, larger build volumes, lower maintenance and significantly lower consumables and running costs. Parts costing only a few dollars compared to hundreds from bureau services.
The Inspire 3D printers can run unattended, they require little maintenance, produce no toxic fumes or materials that require ventilation or protection for operators. They do not need any hazardous chemicals to remove support material which make them ideal for design studio, office and educational institutes.
Inspire 3D printers product strong functional parts in durable ABS plastic which are suitable for snap fits. For a company requiring short run product cycles, this can enable significant savings by eliminating the need for costly investment in tooling.
Introducing an Inspire 3D Printer into a product design cycle shall protect intellectual property by keeping it in house. Boost productivity, reduce time-to-market, catch mistakes earlier, enable more iterations of designs and ultimately improve quality of outcomes and increase profitability.
Specifications:
| |
 |
 |
 |
 |
| Model |
Inspire S200 |
Inspire S250 |
Insprire D255 |
Insprire D290 |
| Build Volume |
200 x 200 x 150 mm |
250 x 200 x 150 mm |
310 x 255 x 255 mm |
320 x 290 x 255 mm |
| (6 litres) |
(7.5litres) |
(20.2 litres) |
(23.7 litres) |
| Smart Support |
Yes |
| Heated build chamber |
Yes |
| Camera Monitor |
No |
No |
Yes |
| Layer thickness with 1 nozzle* |
150 micron (0.15 mm) |
150 micron (0.15 mm) |
150 micron (0.15 mm) |
100 micron (0.10 mm) |
| Layer thickness with 2 nozzles* |
200 micron (0.2mm) |
200 micron (0.2mm) |
175 micron (0.175mm) |
150 micron (0.15mm) |
| System size (mm) |
630 (w) x 660 (d) x 960 (h) |
760 (w) x 730 (d) x 1200 (h) |
720 (w) x 850 (d) x 1650 (h) |
720 (w) x 850 (d) x 1650 (h) |
| Build material |
ABS B601 in 6 colours |
| Support material |
ABS S301 – Easy break away support material |
| Operating Speed |
5 – 60cm3 adjustable |
| Technology |
fused filament fabrication (FFF) |
| Warranty |
12 Month |
| Weight |
65 kg |
150 kg |
170 kg |
190 kg |
| Power |
220-240V, 10A |
| Operating enviroment |
15-20 C, Humidity: 10-50% RH |
| Compatible software |
Windows® XP / Windows® 7 / Windows® 8 |
