EXModel Pro offers a complete reverse engineering workflow. This robust platform streamlines the transition from 3D scanning to manufacturing by simplifying CAD modeling. Equipped with a full suite of tools, it allows you to efficiently convert mesh data into high-quality CAD solid models through a straightforward process. The EXModel is seamlessly integrated with SHINING 3D Scanning software so you can transfer the mesh data to EXModel with a single click, making the transition from scan to design even easier.
Key Features and Uses:
3D Scan to CAD:
EXModel Pro simplifies the transition from 3D scans to CAD by providing tools for mesh editing, feature extraction, and creating parametric CAD models.
Mesh Editing:
The software includes tools for simplifying meshes, removing outliers, and creating watertight surfaces for 3D printing or reverse engineering.
Feature Extraction:
It allows users to extract geometric features like planes, cylinders, cones, and spheres from scanned data, which can be used to reconstruct CAD models.
Primitive Creation:
Users can create basic shapes like planes, cylinders, cones, and spheres from extracted features and establish relationships between them.
Interactive Cutting:
EXModel Pro allows for interactive cutting of meshes to extract 2D sketches, create reference points, and collaborate with world or CAD planes.
Free-Form Modeling:
The software enables the creation of free-form surfaces and blends them with prismatic features, offering flexibility in CAD modeling.
3D Sketching:
Users can sketch directly on the reference mesh, create curves, and fill surfaces for free-form modeling.
Roll/Unroll:
The feature allows flattening or manipulating curved surfaces, providing flexibility for intricate shapes.
Combining Features:
Users can combine different parts and features into a single CAD model.
Compatibility:
EXModel Pro is compatible with various 3D scanners and can import data in formats like STL and PTX.
Applications:
It's used in 3D printing, heritage preservation, aftermarket engineering, AR/VR, healthcare, and education.
Benefits of EXModel Pro:
Efficiency:
It streamlines the process of converting 3D scan data into CAD models, saving time and effort.
Accuracy:
The software's tools allow for precise mesh editing and feature extraction, ensuring accurate CAD models.
Versatility:
It supports various 3D scan formats and provides a range of modeling features, making it suitable for a wide range of applications.
Ease of Use:
EXModel Pro offers a user-friendly interface and step-by-step tutorials, making it easy to learn and use.
