You’ve scanned your manufactured part. You have high-quality point cloud or mesh data. But how do you prove that the physical part matches the original engineering design?
SHINING3D Inspect is powerful, intuitive 3D inspection software designed to answer that specific question. It provides a streamlined workflow for comparing 3D scan data against standard CAD files, allowing Australian engineers, manufacturers, and QA labs to verify tolerances, identify defects, and generate professional reports without the massive price tag associated with legacy metrology suites.
This software is built to balance professional capability with ease of use. It transforms raw scan data into actionable quality control insights.
You don't need to be a metrology veteran to use this software. The interface is designed to guide you through the inspection process logically.
Wide Compatibility: Import scan data from mainstream 3D scanners (STL, PLY, OBJ formats) and compare it directly against standard engineering CAD formats (STEP, IGES, etc.)
Before you can measure, you must align. SHINING3D Inspect offers multiple robust methods to perfectly overlay your scan data onto the CAD model:
Feature Alignment: Align based on geometric features like planes, lines, or points.
Reference Point System (RPS): Use specific datum targets for precise alignment.
Best-Fit Alignment: The software intelligently minimizes deviation across the entire model for a global fit.
Once aligned, the software gives you the tools to interrogate the data fully.
Colour Map Deviation: Instantly visualize the differences between your part and the design with an intuitive "heatmap." See exactly where material is excess (red) or lacking (blue) across the entire surface.
Turn your analysis into a deliverable. SHINING3D Inspect generates detailed, customisable reports complete with visual graphics, colour maps, and data tables to clearly communicate quality status to clients or production managers.
SHINING3D Inspect is the ideal solution for Australian businesses that need reliable quality control without an enterprise-level budget:
Manufacturing: Verify first-off parts or monitor tool wear during production runs.
Reverse Engineering: Check your reconstructed CAD models against the original scan data to ensure accuracy.
Quality Assurance Labs: Perform quick, reliable batch inspections.
We are Australia's leading experts in 3D scanning. Inspection Software is a crucial part of the scanning ecosystem. We don't just sell licenses; we support the entire workflow.
Local Australian Support: With over 25 years experience in 3D Scanning, Reverse Engineering and Inspection. We can help you understand how to integrate this software into your specific manufacturing or engineering environment.
The Complete Solution: We are experts in both the hardware that captures the data and the software that analyses it.
Validate your manufacturing process with confidence. Enquire about SHINING3D Inspect today.
